THORLABS DCC1645C User Manual

351SDK (Software development Kit)
© 2010 Thorlabs
7.7.2
DCx camera Parameter File (INI File)
Using the is_SaveParameters() function, you can save the currently set uEye camera
parameters to a file in INI format (*.ini). To load the saved settings, use is_LoadParameters() .
Only camera-specific ini files can be loaded.
The ini file you want to load has to match the paired camera model.
When loading an ini file, make sure that the image size (AOI) and colour depth parameters in the ini file
match those in the allocated memory. Otherwise, display errors may occur.
uc480 parameter files can also be created and edited manually. The following table shows the
structure of the parameter file. The entries in square brackets [] indicate sections. If a section does
not exist in the ini file, the corresponding camera parameters will not be modified when you load the
file.
Structure of a DCx camera parameter file
Parameter
Description
Value range
Example
[Versions]
uc480.dll
File version of the uc480
SDK
-
3.35.0000
uc480.sys
File version of the USB driver
-
3.35.0000
[Sensor]
Sensor
Full name of the camera
model
-
DCU224-M
[Image size]
Image size settings
Start X
Start point (X coordinate) in
AOI mode
0...(max. w idth
1)
-
Width)
100
Start Y
Start point (Y coordinate) in
AOI mode
0...(max. height
1)
-
Height)
100
Start X absolute
Activate absolute AOI
positioning in the memory
(see is_SetImagePos() )
0, 1
1
Start Y absolute
Activate absolute AOI
positioning in the memory
(see is_SetImagePos() )
0, 1
1
Width
Width of the AOI
Sensor-
dependent
1)
2460
Height
Height of the AOI
Sensor-
dependent
1)
1820
Binning
Activate binning mode and
select factor
Sensor-
dependent
2)
0
216
202
271
271
