THORLABS DCC1645C User Manual

352 DCx camera
© 2010 Thorlabs
Parameter
Description
Value range
Example
Subsampling
Activate subsampling mode
and select factor
Sensor-
dependent
1)
0
[Timing]
Timing parameter settings
Pixelclock
Current pixel clock of the
camera
Sensor-
dependent
1)
32
Framerate
Current frame rate
Depends on
Pixelclock and
image geometry
15.104458
Exposure
Current exposure time
Depends on
Framerate
0.334059
[Selected Converter]
Sets the type of Bayer conversion for the specified colour
format when using colour cameras (see is_SetColorConverter
() ).
For a description of all colour formats, see the Colour and
Memory Formats section.
IS_SET_CM_RGB32
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_RGB24
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_RGB16
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_RGB15
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_Y8
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_RGB8
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_BAYER
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_SET_CM_UYVY
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_UYVY_MONO
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_SET_CM_UYVY_BAYER
Colour format
0, 1, 2, 4, (8
3)
)
2
IS_CM_CBYCRY_PACKED
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_SET_CM_RGBY
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_SET_CM_RGB30
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_SET_CM_Y12
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_SET_CM_BAYER12
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_SET_CM_Y16
Colour format
0, 1, 2, 4, (8
3)
)
8
IS_SET_CM_BAYER16
Colour format
0, 1, 2, 4, (8
3)
)
8
237
350
