410 DCx camera
© 2010 Thorlabs
10.1.5.5
DCC1645C
Table 27: Sensor specifications of the DCC 1645C
Sensor specification
Sensor type
CMOS
Shutter system
Electronic rolling shutter
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.3 Mpixels)
Aspect ratio
5:4
Bit depth
8 bits
ADC resolution
10 bits
Optical sensor class
1/3 inch
Exact sensitive area
4.61 x 3.69 mm
Exact optical sensor diagonal
5.9 mm (1/2.7 inch)
Pixel size
3.6 µm, square
Sensor name, color
Micron MT9M131
Gain
Color model (master/RGB)
3.0x/3.1x
Offset control, mode
Auto/manual, additive
Gain boost
2.0x
Camera timing
Pixel clock range
MHz
5-40
*1)
Pixel clock range (with subsampling/binning)
MHz
5-40
*1)
Frame rate (freerun mode)
fps
25
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
23
*2)
Exposure time in freerun mode
ms
0.037 *
2)
- 10s
*3)
Exposure time in trigger mode
ms
0.037 *
2)
- 10s
*3)
AOI
Mode
Horizontal
*4)
+ Vertical
*4)
AOI image width, step width
Pixels
32 - 1280, 4
AOI image height, step width
Pixels
4 - 1024, 2
AOI position grid horizontal, vertical
Pixels
4, 2
AOI frame rate, 1024 x 768 pixels (XGA)
fps
39
AOI frame rate, 640 x 480 pixels (VGA)
fps
89
AOI frame rate, 320 x 240 pixels (CIF)
fps
262
Binning
Mode
-
