409Appendices
© 2010 Thorlabs
Subsampling
Mode
Horizontal
*4)
+ Vertical
*4)
Frame rate w/ 2x subsampling, 640 x 512
pixels
fps
79
Frame rate w/ 4x subsampling, 320 x 256
pixels
fps
219
Frame rate w/ 8x subsampling, 160 x 128
pixels
fps
511
Connected load
*5)
W
0.5-1.0
*1)
The maximum possible pixel clock frequency depends on the PC hardw are used.
*2)
Requires maximum pixel clock frequency.
*3)
Requires minimum pixel clock frequency.
*4)
Use of this function increases the frame rate.
*5)
The connected load depends on the sensor model and the pixel clock setting.
Monochrome
Figure 113: Sensor sensitivity of the DCC1545M
