390 DCx camera
© 2010 Thorlabs
CMOS
DCC1545M
0.525
1.50
1.270
18.97
19.32
2.480
DCC1645C
0.550
1.50
1.45
19.16
19.51
2.500
CCD
DCU223x-xx
0.75
1.5
2.81
20.59
20.94
4.78
DCU224x-xx
0.75
1.5
2.81
20.59
20.94
4.83
Calculation example: DCC1545C with IR-cut filter
(a = 17.526 mm, d = 0.525 mm, nGlass = 1.50, f = 1mm, nFilter = 1.53; )
Calculating the flange back distance for DCC cameras models with CS-mount
NOTE
For USB DCx cameras with CS-mount, the flange back distance is only 12.526 mm!
Table 18: Distances and dimensions for calculating the flange back distance
USB DCx
sensor
Sensor glass
d [mm]
Distance
e [mm]
Sensor height
h [mm]
CMOS
154xLE
0.55
1.27 +/- 0.085
2.21 +/- 0.27
164xLE
0.55
1.45 +/- 0.125
2.35 +/- 0.15
