© 2016 Thorlabs Scientific Imaging
4 Programming (SDK)
223
Status Flags in UC480_AUTO_INFO::AShutterPhotomCaps
The entire field of view is used for metering.
AS_PM_SENS_CENTER_WEIGHTED
Metering is based on the entire field of view, but
gives greater emphasis to the center area of the
image.
Only a small area in the image center is used for
metering.
Metering is based on that part of the field of view
that corresponds to the portrait format.
Metering is based on that part of the field of view
that corresponds to the landscape format.
Status Flags in UC480_AUTO_INFO::AGainPhotomCaps
The entire field of view is used for metering.
AG_PM_SENS_CENTER_WEIGHTED
Metering is based on the entire field of view, but
gives greater emphasis to the center area of the
image.
Only a small area in the image center is used for
metering.
Metering is based on that part of the field of view
that corresponds to the portrait format.
Metering is based on that part of the field of view
that corresponds to the landscape format.
Status Flags in UC480_AUTO_INFO::AAntiFlickerCaps
Anti flicker function disabled.
The anti flicker mode is selected automatically
(50 or 60 Hz).
ANTIFLCK_MODE_SENS_50_FIXED
The anti flicker mode is set to a fixed value of 50
Hz.
ANTIFLCK_MODE_SENS_60_FIXED
The anti flicker mode is set to a fixed value of 60
Hz.
Status Flags in UC480_AUTO_INFO::SensorWBModeCaps
Disables the sensor's auto white balance
Sensor automatically determines auto white
balance
Sensor automatically determines auto white
balance using the Gray World algorithm. This
algorithm assumes that the average color value
in the scene is gray.
WB_MODE_INCANDESCENT_LAMP
Sensor sets auto white balance to incandescent
light
Sensor sets auto white balance to fluorescent
light (daylight type)
