5.2 Model Naming Conventions
In the table below, you will find an overview of all the models in the DCx camera series.
DC
X
##
#
X
Short for "Digital Camera
C CMOS
U CCD
Sensor and shutter type
12
15/16
22
32
CMOS Global Shutter
CMOS Rolling Shutter
CCD Progressive Scan
CMOS Global Shutter, USB3
Resolution
3
4, 40, 45
6
XGA
SXGA
1024 x 768 (0.78 MPixel)
1280 x 1024 (1.30 MPixel)
1936 x 1216 (2.35 MPixel)
Color / Mono
M
C
N
Monochrome sensor
Color sensor
Near Infrared sensor
5.3 Camera and Sensor Data
In this chapter the technical properties of the sensors are listed. You can look up e.g. binning
factors. Also you will find the parameters for the different interfaces.
Cameras with CMOS sensors
DCC1240x / DCC3240x
DCC1545M
DCC1645C
Cameras with CCD sensors
DCU223x
DCU224x
Note:
The diagrams shown in the sensor specifications section indicate the relative sensitivities of the
DCx Cameras in the spectral range. Therefore, the characteristic curves cannot be compared to
each other.
