4 Programming (SDK)
313
IS_INVALID_PARAMETER
One of the submitted parameters is outside the
valid range or is not supported for this sensor or
is not available in this mode.
IS_NO_SUCCESS
General error message
IS_NOT_SUPPORTED
The camera model used here does not support
this function or setting.
IS_SUCCESS
Function executed successfully
Related functions
is_GetFramesPerSecond()
is_GetFrameTimeRange()
is_Exposure()
is_SetOptimalCameraTiming()
is_SetFrameRate()
is_SetAutoParameter()
is_SetBinning()
is_SetSubSampling()
is_AOI()
Example 1
UINT nNumberOfSupportedPixelClocks = 0;
INT nRet = is_PixelClock(hCam, IS_PIXELCLOCK_CMD_GET_NUMBER,
(void*)&nNumberOfSupportedPixelClocks,
sizeof(nNumberOfSupportedPixelClocks));
if ((nRet == IS_SUCCESS) && (m_nNumberOfSupportedPixelClocks > 0))
{
// No camera has more than 150 different pixel clocks.
// Of course, the list can be allocated dynamically
UINT nPixelClockList[150];
ZeroMemory(&nPixelClockList, sizeof(nPixelClockList));
nRet = is_PixelClock(hCam, IS_PIXELCLOCK_CMD_GET_LIST,
(void*)nPixelClockList,
nNumberOfSupportedPixelClocks * sizeof(UINT));
}
Example 2
UINT nRange[3];
ZeroMemory(nRange, sizeof(nRange));
// Get pixel clock range
INT nRet = is_PixelClock(hCam, IS_PIXELCLOCK_CMD_GET_RANGE, (void*)nRange, sizeof(nRange));
if (nRet == IS_SUCCESS)
{
UINT nMin = nRange[0];
UINT nMax = nRange[1];
UINT nInc = nRange[2];
}
Example 3
UINT nPixelClock;
// Get current pixel clock
nRet = is_PixelClock(hCam, IS_PIXELCLOCK_CMD_GET, (void*)&nPixelClock, sizeof(nPixelClock));
