DCx Camera Functional Description and SDK Manual
hCam
Camera handle
pval2: returns the maximum permitted value
Photometric settings for auto gain control/auto exposure shutter
IS_SET_SENS_AUTO_SHUTTER_PHOTOM
Sets the photometry mode for auto exposure
shutter.
Control parameters
pval1: defines which fields of view are used for
auto exposure shutter (see is_GetAutoInfo()):
AS_PM_NONE
AS_PM_SENS_CENTER_WEIGHTED
AS_PM_SENS_CENTER_SPOT
AS_PM_SENS_PORTRAIT
AS_PM_SENS_LANDSCAPE
IS_GET_SENS_AUTO_SHUTTER_PHOTOM
Returns the photometry mode for auto exposure
shutter.
Control parameters
pval1: returns the current setting
IS_GET_SENS_AUTO_SHUTTER_PHOTOM_DEF
Returns the default photometry mode for auto
exposure shutter.
Control parameters
pval1: returns the default
IS_SET_SENS_AUTO_GAIN_PHOTOM
Sets the photometry mode for auto gain control.
Control parameters
pval1: defines which fields of view are used for
auto gain control (see is_GetAutoInfo()):
AG_PM_NONE
AG_PM_SENS_CENTER_WEIGHTED
AG_PM_SENS_CENTER_SPOT
AG_PM_SENS_PORTRAIT
AG_PM_SENS_LANDSCAPE
IS_GET_SENS_AUTO_GAIN_PHOTOM
Returns the photometry mode for auto gain
control.
Control parameters
pval1: returns the current setting
IS_GET_SENS_AUTO_GAIN_PHOTOM_DEF
Returns the default photometry mode for auto
gain control.
Control parameters
pval1: returns the default
Adjusting auto white balance
IS_SET_AUTO_WB_OFFSET
Sets the offset values for the red and blue
channels.
Control parameters
pval1: defines the red level offset (-50...50)
pval2: defines the blue level offset (-50...50)
IS_GET_AUTO_WB_OFFSET
Returns the offset values for the red and blue
