DCx Camera Functional Description and SDK Manual
Return values
When used with
IS_GET_EXTERNALTRIGGER
Returns the current setting
When used with
IS_GET_TRIGGER_STATUS
Returns the current signal level at the trigger
input
When used with
IS_GET_SUPPORTED_TRIGGER_MODE
Returns the supported modes linked by logical
ORs
IS_INVALID_CAPTURE_MODE
The function can not be executed in the current
camera operating mode (free run, trigger or
standby).
IS_INVALID_CAMERA_HANDLE
Invalid camera handle
IS_NO_SUCCESS
General error message
IS_SUCCESS
Function executed successfully
Related functions
is_CaptureVideo()
is_FreezeVideo()
is_ForceTrigger()
is_SetTriggerCounter()
is_SetTriggerDelay()
is_IO()
Example
//Enable trigger mode and set high-active flash mode.
is_SetExternalTrigger(hCam, IS_SET_TRIGGER_SOFTWARE);
// Set the flash to a high active pulse for each image in the trigger mode
UINT nMode = IO_FLASH_MODE_TRIGGER_HI_ACTIVE;
is_IO(m_hCam, IS_IO_CMD_FLASH_SET_MODE, (void*)&nMode, sizeof(nMode));
is_FreezeVideo(hCam, IS_WAIT);
Sample programs
uc480 Simple Trigger (C++)
uc480 IO (C++)
