DCx Camera Functional Description and SDK Manual
hCam
Camera handle
maximum row position for DR_SET_USER_SYNC.
Example
DR_LOAD_OVERLAY_FROM_FILE
Direct3D only: Loads a bitmap image (*.BMP file)
into the overlay area. If the bitmap image is larger
than the overlay area, the bitmap image is
clipped. Example
DR_CLEAR_OVERLAY
Deletes the data of the overlay area by filling it
with black color. Example
DR_STEAL_NEXT_FRAME
Copies the next image to the active user memory
(Steal function).
More details
Using the pParam parameter, you specify when
the function should return:
IS_WAIT: The function waits until the image
save is complete.
IS_DONT_WAIT: The function returns
immediately.
Example
DR_SET_STEAL_FORMAT
Defines the color format for the Steal function.
More details
For a list of all available color formats, see the
function description for is_SetColorMode(). The
default is IS_CM_BGRA8_PACKED (RGB 32).
Example
DR_GET_STEAL_FORMAT
Returns the color format setting for the Steal
function. Example
DR_SET_HWND
Sets a new window handle for image output in
Direct3D. Example
DR_CHECK_COMPATIBILITY
Returns whether the graphics card supports the
uc480 Direct3D functions. Example
DR_GET_OVERLAY_DATA
OpenGL only: Returns a pointer to the overlay.
DR_UPDATE_OVERLAY_DATA
OpenGL only: Updates the overlay.
pParam
Pointer to a function parameter, whose function
depends on nCommand.
nSize
Size (in bytes) of the data object or array.
