THORLABS DCU223 SERIES Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging242
DCx Camera Functional Description and SDK Manual
BYTE
byReserved1[4]
Reserved
unsigned long long
u64TimestampDevice
Internal timestamp of image capture
(tick count of the camera in 0.1 µ s
steps)
UEYETIME
TimestampSystem
Structure with timestamp information in
PC system time format, see UEYETIME
below
DWORD
dwIoStatus
With DCC3240x Cameras: Returns
the states of the digital I/Os at the time
of image capture:
Digital input (trigger): Pending signal
GPIO as input: Pending signal
GPIO as output: Set level
With all other cameras, dwIoStatus is
empty. See dwIOStatus below.
WORD
wAOIIndex
AOI index (only AOI sequence mode of
DCC1240x)
WORD
wAOICycle
Readout cycles (only AOI sequence
mode of DCC1240x)
unsigned long long
u64FrameNumber
Internal image number
DWORD
dwImageBuffers
Number of image buffers existing in
the camera
DWORD
dwImageBuffersInUse
Number of image buffers in use in the
camera
DWORD
dwReserved3
Reserved
DWORD
dwImageHeight
Image height
DWORD
dwImageWidth
Image width
Status flags in UC480IMAGEINFO::dwIoStatus
Bit combination
State of digital input
State of GPIO 1
State of GPIO 2
000
0
0
0
001
0
0
1
010
0
1
0
011
0
1
1
100
1
0
0
101
1
0
1
110
1
1
0
111
1
1
1
Contents of the UC480IMAGEINFO::UEYETIME structure
