THORLABS PM100D User Manual

6.4 PM100D SCPI Commands
6.4.2.3.5 SENSe subsystem commands
Command Description
[SENSe]
Path to SENSe subsystem. (SCPI Vol.2 §18)
AVERage
[:COUNt] <value
Sets the averaging rate (1 sample takes approx. 3ms)
[:COUNt]?
Queries the averaging rate
CORRection
[:LOSS[:INPut[:MAGNitude]]]
{MINimum|MAXimum|DEFault|
<numeric_value>}
Sets a user attenuation factor in dB
[:LOSS[:INPut[:MAGNitude]]]?
[{MINimum|MAXimum|DEFault}]
Queries the user attenuation factor
COLLect
ZERO
[:INITiate]
Performs zero adjustment routine
ABORt
Aborts zero adjustment routine
STATe?
Queries the zero adjustment routine state
MAGNitude?
Queries the zero value
BEAMdiameter {MINimum|
MAXimum|DEFault|
<numeric_value>[mm]}
Sets the beam diameter in mm
BEAMdiameter? [{MINimum|
MAXimum|DEFault}]
Queries the beam diameter
WAVelength {MINimum|
MAXimum|
<numeric_value>[nm]}
Sets the operation wavelength in nm
WAVelength? [{MINimum|
MAXimum}]
Queries the operation wavelength
52

THORLABS PM100D Specifications

General

Data Logging	Yes
Storage Temperature Range	-20 °C to 70 °C
Power Accuracy	±0.5% of reading
Interface	USB
Power Supply	USB or AC Adapter
Display Update Rate	10 Hz
Detector Type	Photodiode or Thermopile (Sensor Dependent)
