MAINTENANCE
ELITE 3000
10.7 CONNECTION DIAGRAM
POWER CABLE
120V / 60Hz
TERMINAL STRIP
blue
black
green/yellow
green/yellow
blue
brown
P/N 2392144
P/N 2370294black
red
blue
OPERATION CAPACITOR
C = 80µF
250V
MOTOR SWITCH 20A
P/N 0522 622
MOTOR
white P/N 2427577
blue
brown P/N 2370299
