Titan ELITE 3000 User Manual

9
OVERVIEW
ELITE 3000
2.3 SPRAYER CONFIGURATIONS
The Elite 3000 is oered in multiple congurations. It can either
be used as a high-cart unit with a rigid suction set (Figure 1) or a
low cart unit with a exible suction set (Figure 2).
i
The drip cup (1) can be oriented accordingly
based on the conguration being used.
1
FIGURE 1
1
FIGURE 2
TOPFEED HOPPER ACCESSORY
The low cart conguration can also be used with a top-feed
hopper which is available for separate purchase.
FIGURE 3
i
The pail bracket will need to be removed in order
to install the hopper to the unit.

Titan ELITE 3000 Specifications

General

Type	Airless
Spray Pattern	Adjustable
Max Pressure	3000 PSI
Power Source	Electric
Hose Length	50 ft
Spray Tip Size	0.015 in
