Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version:3.1 Document Version:1.01 28
Figure 14: Pictorial view of TM5-700 / TM5M-700 / TM5X-700 Movement Range Diagram
Figure 15: Top View of TM5-700 / TM5M-700 / TM5X-700 Movement Range
Operator
Position
Warning: Risk of crushing
within the operating area of
the arm.
Warning: Risk of collision within
the operating area of the arm.
