22
COMPONENTS
Tomogram live image area
This area displays the tomogram live image. Perform the operation on the live image.
• Z lock position : Displays the center position of the displayed tomogram.
• Z lock position display bar : Indicates the Z lock position changeable range. By touching an
optional position on the bar, you can move the center position of the
displayed tomogram to the touched position.
Stereoscopic image
[Image Quality]
level meter
Image Quality value
(IQV)
Z lock position
display bar
Z lock position
[Optimize] button
[Manual] button
Live image
Z lock position is moved.
To Next Page
