Getting Acquainted
P/N 7010-0816
1-19
The ODU-to-alligator clips cable (p/n 14-008097-01LF) connects
the charging cradle or receiver to an auxiliary battery for powering the
receiver during survey operations (Figure 1-10).
Figure 1-10. Auxiliary Power Cable – ODU-to-Alligator Clips
The 2m fixed height Tripod and Pole 1.(22-050911-01 and 22-
050908-01). Pole not pictured. Tripod for the HiPer Ga/Gb
(Figure 1-11).
Figure 1-11. Tripod
