Topcon HiPer Ga User Manual

Configuring the Receiver
P/N 7010-0816
3-11
5. Select ConfigurationReceiver.
6. Click Set all parameters to defaults (Figure 3-7).
Figure 3-7. Set All Parameters to Defaults
7. Click the MINTER tab, enter the following settings
(Table 3-4), and then click Apply (Figure 3-8).
NOTICE
Click Apply after making any configuration
change; otherwise, the receiver will not register the
change.
Table 3-4. Receiver Parameters for the MINTER Tab
Parameter Base Receiver Rover Receiver
Recording
interval
Enter 15 seconds.
Elevation
mask angle
Enter 15 degrees.
File name
prefix
Enter a unique ID, such as the last 3 digits of receiver’s serial
number.
FN key mode (starts/stops data recording using the FN key)
For Static data recording,
select LED blink mode switch.
For RTK data recording,
select Occupation mode
switch.

Topcon HiPer Ga Specifications

General

Brand	Topcon
Model	HiPer Ga
Category	Receiver
Language	English
