BASIC OPERATIONS
PRINT-OUT OF MEASUREMENT VALUES
This instrument can print out measurement values by a printer.
1 Check the Measurement screen is on.
2 Tap the button on the control panel.
Measurement values on the monitor are printed out.
After being printed out, the measurement values on the screen are deleted automatically.
NOTE:
• To avoid a paper jam in the printer, do not feed the paper if it is
partly cut or wrinkled.
• To avoid discoloring of the printer paper (particularly the recording
area) during storage, use a polypropylene bag and not one con-
taining plasticizer (PVC, etc.).
• To avoid discoloring of the printer paper (particularly the recording
area) after pasting, use water-soluble glue and not one containing
solvent.
• Since the printer paper is thermosensitive, it is not suitable for
keeping records for a long period. If necessary, prepare copies
separately.
When the cylindrical refractive power is "0," the direction of astigmatic axis and
measurement values are not displayed/printed.
When a red line is printed at the end of the printer paper, replace it with a new one.
For details about the replacement of printer paper, see “PRINTER PAPER SET-
TING” on page 21. 58mm wide printer paper (example: TP-50KJ-R, Nippon
Paper) is recommended.
"CLOSE PRT COVER" is indicating that the printer cover is left opened, ensure
that the printer cover is completely closed.
When auto print is setting is "ON" in the initial setting, measurement is performed
under Auto mode, and measurement results are printed out automatically. (See
page 48.)
After printing out measurement values, the measuring head moves to the "finish
mode" position of the initial setting.
When the Auto cut setting is off and you need to cut a printer form, the way is that
erase the measurement value by tapping the button, and tap the
button. (See page 50.)
