Topcon KR-1 - OUTPUT USING RS232 C; INPUT USING USB; OUTPUT USING LAN

43
OPTIONAL OPERATIONS
OUTPUT USING RS232C
This instrument can output data to a PC, etc via the RS232C interface.
1 Connect the interface cable to RS232C OUT.
Refer to “CONNECTING EXTERNAL I/O TERMINALS” on page 20.
2 Set up of data communication settings.
For details, refer to “DATA COMMUNICATION (COMM)” on page 52.
3 Perform measurements.
4 Tap the button of the control panel.
When output is completed, "RS232C SUCCESS" is displayed on the screen.
INPUT USING USB
This instrument can input ID numbers from a bar code reader, etc via the USB.
1 Check the connection of USB IN.
For connection, refer to “CONNECTING EXTERNAL I/O TERMINALS” on page 20.
2 Input ID numbers from the external device.
The inputted ID numbers are displayed on the screen.
OUTPUT USING LAN
This instrument can output data to a PC, etc via the LAN interface.
1 Connect the network cable to LAN OUT.
For connection, refer to “CONNECTING EXTERNAL I/O TERMINALS” on page 20.
2 Set up of LAN connection settings.
For details, refer to “LAN CONNECTION (LAN)” on page 53.
3 Perform measurements.
4 Tap the button of the control panel.
When output is completed, "LAN SUCCESS" is displayed on the screen.
For explanation of messages during communication refer to the "MESSAGE
LIST" on page 54.
PRINT OUT
PRINT OUT
