Topcon KR-1 - MEASURING THE RIGHT EYE ONLY; MEASURING THE LEFT EYE ONLY; MEASUREMENT OF CORNEA DIAMETER

39
OPTIONAL OPERATIONS
MEASUREMENT OF CORNEA DIAMETER
MEASUREMENT ON THE ACTUAL IMAGE
1 Tap the button/ button to select the right/left eye.
2 Tap the button.
3 The Cornea Diameter Measurement screen is displayed, and The positioning bar is dis-
played.
