Topcon KR-1 - KRT (Print setting on KRT mode); DATA COMMUNICATION (COMM)

52
SETTING FUNCTIONS ON SETUP SCREEN
DATA COMMUNICATION (COMM)
Comm contains settings related to data output with the external device.
KRT
(Print setting on
KRT mode)
KRT
print order
D/mm
KRT data is printed as follows,
D (corneal refractive power)/mm (corneal curvature).
D/mm
mm/D
KRT data is printed as follows,
mm (corneal curvature)/D (corneal refractive power).
KRT format
ALL All the measurement value is printed.
ALL
AVE Printout only typical value.
KRT style
HV
Display style of KRT measurement results is set to
HV (horizontal/vertical).
R1R2
R1R2
Display style of KRT measurement results is set to
R1R2 (flat/steep meridian).
KRT print
format
HV KRT measurement result is printed in simple format.
R1R2
R1R2 KRT measurement result is printed in full format.
KRT average
OFF Do not print KRT average value.
ON
ON Print KRT average value.
KRT cylinder
OFF Do not print kerato-cylinder value and axial angle.
ON
ON Print kerato-cylinder value and axial angle.
Corneal
diameter
OFF Do not print corneal diameter.
ON
ON Print corneal diameter.
Description Options Details Initial value
Output Data
REF Only REF data are output.
ALLKRT Only KRT data are output.
ALL All measurement value is output.
Format
OLD OLD TOPCON format
OLD
NEW NEW TOPCON format
STD1 TOPCON STD1 format
STD2 TOPCON STD2 format
STD4 TOPCON STD4 format
Output port
OFF RS-232C port is disabled.
OFF
ON RS-232C port is enabled.
Baudrate
2400bps Baudrate value:2400
2400bps
9600bps Baudrate value:9600
Description Options Details Initial value
