Toro Groundsmaster 4500-D Series - Page 224

RearAxleandFrontWheelMotorService(continued)
2
3
6
8
9
1
5
7
4
1
2
3
4
REAR AXLE MOTOR FLUSHING VALVE
10
g275435
Figure116
1.Plug6.Plug
2.O−ring7.O−ring
3.Centeringspring8.Centeringspring
4.Springretainingwasher9.Oricepoppet
5.Shiftspool
10.Endcap
Note:ThefrontwheelmotorsonyourGroundsmasterareidentical(Figure
115).Therearaxlemotorincludesaushingvalveforcoolingoftheclosedloop
tractioncircuitandthereforehassomedifferencesfromthefrontmotors(Figure
116).Serviceofthewheelandaxlemotorsusesthesameprocedure.
Note:Forserviceofthefrontwheelandrearaxlemotors,seetheSauer−Danfoss
KandLFrameVariableMotorsServiceManual.
HydraulicSystem:ServiceandRepairs
Page5–122
Groundsmaster
®
4500-D/4700-D
19245SLRevA
