Disassembly(Figure300)(continued)
4
1
1
2
3
5
g277084
Figure301
1.Bearing4.Innerbearingspacer
2.Spacerring5.Outerbearingspacer
3.Largesnapring
Assembly(Figure300)
Note:Areplacementspindlebearingsetcontainstwo(2)bearings,aspacer
ringandalargesnapring(items1,2and3inFigure301).Thesepartscannot
bepurchasedseparately.Donotmixbearingsetcomponentsfromonedeck
spindletoanother.
Note:Areplacementbearingspacersetincludestheinnerspacerandouter
spacer(items4and5inFigure301).Donotmixbearingspacersfromone
deckspindletoanother.
IMPORTANT
Ifnewbearingsareinstalledintoausedspindlehousing,itmaynot
benecessarytoreplacetheoriginallargesnapring.Iftheoriginal
largesnapringisingoodconditionwithnoevidenceofdamage(e.g.
spunbearing),leavethesnapringinthehousinganddiscardthe
largesnapringthatcomeswiththenewbearings.Ifthelargesnap
ringisfoundtobedamaged,replacethesnapring.
1.Iflargesnapringwasremovedfromspindlehousing,installsnapringinto
housinggroove.Makesuresnapringisfullyseatedingroove.
2.Installouterbearingspacerintotopofspindlehousing.Thespacershouldt
againstthelargesnapring.
CuttingDecks:ServiceandRepairs
Page9–8
Groundsmaster
®
4500-D/4700-D
19245SLRevA
