Toro Sentinel User Manual

36
Maximum/Minimum Flows (2 Fields to set: Station number and max/min flow in GPM)
Specify/enter the maximum or minimum ow values in gallons per minute for each individual station.
Expected Flows (2 Fields to set: Station number and expected flow in GPM)
Enter/edit the Expected Flow values (in gallons per minute) for individual stations. Expected ow values will be displayed even if there is no
ow meter to collect and read actual ow values.
2 3 41
ENTER
- OR -
ENTER
- OR -
Maximum Flows
STN 001 9999 GPM
** SAVED! **
STN 001 9999 GPM
STATION SETTINGS
Maximum Flows
2 3 41
ENTER
- OR -
ENTER
- OR -
Expected Flows
STN 001 0010 GPM
** SAVED! **
STN 001 0010 GPM
STATION SETTINGS
Expected Flows

Toro Sentinel Specifications

General

Type	Modular
Mounting	Wall
Enclosure	NEMA 3R
Communication	Ethernet
Water Management	Master Valve
Compatibility	Toro
Stations	Up to 48
Power Supply	Included
