Toro Sentinel User Manual

2
Control Module Display
The Sentinel Controller has a six-line LCD screen. When rst powered on,
the display will be in its standard mode.
1. Current time (HH:MM), day, week number of schedule (up to six
weeks), and date.
2. If running, Actual ow (A#####) and Expected ow (E#####).
• Actual Flow: 5-digit numeric indicator of current ow through
connected ow sensor.
• Expected Flow: 5-digit numeric indicator of expected ow
based on current stations operating and their expected ows.
3. Current amperage draw
Front LEDs
The front of the Sentinel Control Module has ve LEDs to alert
the user to particular conditions.
Alarm
A B
Hold Irrigation
LED Purpose
A Flow 1 activity. Light turns off within a couple minutes of no ow input.
B Flow 2 activity. Light turns off within a couple minutes of no ow input.
Alarm (Red) Flashing light if any alarm; steady light if any warnings.
Hold (Amber) A steady light indicates program or station days off.
Irrigation (Green) Steady light on if an irrigation program is currently running.
1
1
2
2
3
3
The Sentinel system takes rougly fteen (15) seconds to
display information up once plugged in. Please be patient.

Toro Sentinel Specifications

General

Type	Modular
Mounting	Wall
Enclosure	NEMA 3R
Communication	Ethernet
Water Management	Master Valve
Compatibility	Toro
Stations	Up to 48
Power Supply	Included
