9
Icons Explained
There are several icons used throughout the manual to portray certain functions.
Icon Meaning
Turn the Control Knob to change values in the currently highlighted eld.
Press the button / knob pictured under the nger.
A line under characters on the LCD screen indicates a eld that can be adjusted with the Control Knob.
