Chapter 4: Sentinel AC 2-Wire Addendum
Getting the Sentinel satellite to work with an AC 2-Wire system
requires a few extra steps.
Steps
1. Conrm the serial port connected to the 2-Wire output board is
set to BL/TORO AC 2-Wire.
The instructions below assume the 2-Wire output board is
connected to serial port 1 (from bottom of TM).
a. Press Option button. Select Port 1/Ft Function.
b. Use Knob to select BL/Toro AC 2-Wire.
Press ENTER.
2. For all decoder stations, conrm that the Station Type is set to
Toro AC 2-Wire.
a. Press Station Settings button. Select Station Type.
b. Use the Control Knob to adjust the station number.
Every station should already be set to Toro-AC-2W.
c. If a station is not, use the right-arrow button to move to
the Station Type eld.
d. Use Knob to select Toro-AC-2W.
Press ENTER.
3. The stations must then be mapped to the particular decoder
address. The address of each decoder should be afxed to each
individual decoder.
a. Press Station Settings button. Select Map Stations.
b. Use Knob to select desired station.
c. Use arrow buttons to move to Stn_Adr eld.
d. Use Knob to adjust value as necessary. Press ENTER.
e. Repeat as necessary.
4. If necessary, it is possible to reprogram the address for each
decoder using the Programmer port. Reprogramming decoder
addresses might be necessary if the decoders are not addressed
sequentially or if decoder addresses are unknown (for example,
the decoder address label has fallen off).
a. Press Option button.
Select Prog Toro AC Decoder.
b. Use Knob to adjust New Address value. Press ENTER.
Port 1/Ft Function
BL/TORO AC 2-Wire
Station Type
STN 001: TORO-AC-2W
Map Stations
STN->PCd/MU:Stn_Adr
001->000/001:001_000
Prog Toro AC Decoder
Current Address 001
New Address 002
Port 1 of 1

Toro Sentinel Specifications

General

Type	Modular
Mounting	Wall
Enclosure	NEMA 3R
Communication	Ethernet
Water Management	Master Valve
Compatibility	Toro
Stations	Up to 48
Power Supply	Included
