Figure43
1.Notetheclearancebetweenthelldeviceandtheoil-ll
neck.
Important:Whenaddingengineoilorlling
oil,theremustbeclearancebetweentheoil
lldeviceandtheoilllneckinthevalve
coverasshowninFigure43.Thisclearance
isnecessarytopermitventingwhenadding
oil.
8.Installthellercapontothellerneck(Figure
42).
9.Firmlyinstallthedipstick(Figure42).
ChangingtheEngineOilandFilter
ServiceInterval:Aftertherst50hours
Every200hours
1.Raisethebedandplacethesafetysupporton
theextendedliftcylindertoholdupthebed.
2.Alignalargedrainpanundertheoil-drainplug
(Figure44).
g025525
Figure44
1.Drainplug
2.Forward
3.Removethedrainplugandlettheoilowintoa
drainpan(Figure44).
4.Whentheoilstopsdraining,installthedrain
plug.
5.Removetheoillterfromthelteradapter
(Figure45).
g025524
Figure45
1.Forward3.Filteradapter
2.Oillter
6.Wipecleanthesealingbaseoftheofthelter
adapter(Figure45).
7.Applyalightcoatofcleanoiltothesealofthe
newlter.
8.Installthelteruntilthegasketcontactsthe
sealingbaseofthelteradapter,thentighten
thelterclockwiseandadditional1/2to2/3of
aturn(Figure45).
Note:Donotovertightentheengine-oillter.
42
