Toshiba TOSVERT VF-nC3 User Manual

E6581595
I-6
9
■Current reduction
According to the carrier frequency f300 setting, you may need to reduce the inverter’s continuous
output current. Reduction rates vary depending on the capacity of the inverter.
[Three-phase/Single-phase 200 V class]
Inverter model
Ambient temperature
Input voltage 200V to 240V
PWM Carrier frequency
2 to 4 kHz 5 to 12 kHz
VFNC3-2001P
VFNC3S-2001PL
40C or less *1
0.7 A 0.7 A
VFNC3-2002P
VFNC3S-2002PL
40C or less *1
1.4 A 1.4 A
VFNC3-2004P
VFNC3S-2004PL
40C or less *1
2.4 A 2.4 A
VFNC3-2007P
40C or less *1
4.2 A
3.6 A
VFNC3S-2007PL 3.2 A
VFNC3-2015P
VFNC3S-2015PL
40C or less *1
7.5 A
7.5 A
Above 40 to 50C *2
7.1 A
VFNC3-2022P
40C or less *1
10.0 A
8.5 A
VFNC3S-2022PL 9.1 A
VFNC3-2022P
VFNC3S-2022PL
Above 40 to 50C *2
10.0 A 7.5 A
VFNC3-2037P
40C or less *1
16.7 A 14.0 A
Above 40 to 50C *2
[Single-phase 100 V class]
Inverter model
Ambient temperature
Input voltage 100V to 120V
PWM Carrier frequency
2 to 4 kHz 5 to 12 kHz
VFNC3S-1001P
40C or less *1
0.7 A 0.7 A
VFNC3S-1002P
40C or less *1
1.4 A 1.4 A
VFNC3S-1004P
40C or less *1
2.4 A 2.4 A
VFNC3S-1007P
40C or less *1
4.2 A 4.0 A
Above 40 to 50C *2
*1: Maintain the ambient temperature of 40°C or less for the compliance with UL standard.
*2: Remove the protective label on the top of the inverter for the compliance with UL standard for the
ambient temperature above 40C to 50C.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
