Enter a desired name ("POINT00011") and press the EXE key, as already
described in Para. 5.2. The display changes as follows:
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 5 = 300 , 300 , 3 00 ,
P O I N T 0 0 0 1 1 = 0 ,0 , 0,
↓
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
0 w/ . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
(3) Cautions
• For the newly added positional data, zero (0) is set for all elements.
• When you have pressed the ESC key without specifying the name, addition of
the new data is canceled and the system returns.
STE 80720
– 5-14 –
