OPERATOR’S MANUAL
series Robot Controller
5.5 Detailed Coordinate Data Display Mode
The detailed coordinate data display mode displays one (1) coordinate data on the
full screen. In this mode, it is possible to edit the coordinate data name and
element.
An example of display is given below.
T R A N S 0 0 0 0 2 [ 3 / 11]
X : 5 0 0 . 0 0 0
Y : 0 . 0 0 0
Z : 0 . 0 0 0
C : 0 . 0 0 0
T R A N S 0 0 0 0 2
S A V E T E A C H D I R W O R K F I N D >
Each time the NEXT key is pressed, the menu is changed over as follows:
N O S A V >
An inversely displayed section in the data is called the "main cursor" which
indicates that this data is selected for editing.
For the data of [nnnn/mmmm] displayed on the 1st line, "nnnn" signifies the
number of positional data contained in the selected coordinate system.
"mmmm" represents the total number of positional data in all coordinate systems.
STE 80720
– 5-66
