OPERATOR’S MANUAL
series Robot Controller
2.3 Main Power and Servo Power of TSL3000 Controller
2.3.1 Controller Front Panel (TSL3000)
The TSL3000 front panel is shown below.
(1) Keyswitch : Used to select operation master mode.
(2) POWER : Indicates that the main power is turned on.
(3) READY : Indicates that the system was started properly after the main
power was turned on.
(4) SVON : Indicates that the servo power is turned on.
(5) RUN : Turns on when a program is being executed.
(6) ALARM : Indicates that an alarm has occurred.
STE 80720
– 2-10 –
