TP-Link TL-SG5412F User Manual

GENERAL: Supporte
d. The default VLAN of the port can not
be voice VLAN and the egress rule of the access port in the
default VLAN should be TAG.
ACCESS: Supported.
TRUNK: Not supported.
UNTAG voice
stream
GENERAL: Supported. The default VLAN of the port can not
be voice VLAN and the egress rule of the access port in the
voice VLAN should be UNTAG.
ACCESS: Not supported.
TRUNK：Supported. The default VLAN of the port can not be
voice VLAN.
TAG voice
stream
GENERAL：Supported. The default VLAN of the port can not
be voice VLAN and the egress rule of the access port in the
default VLAN should be TAG.
ACCESS: Supported. The default VLAN of the port should be
voice VLAN.
TRUNK: Not supported.
Manual Mode
UNTAG voice
stream
GENERAL: Supported. The default VLAN of the port can not
be voice VLAN and the egress rule of the access port in the
default VLAN should be UNTAG.
Table 9-2 Port voice VLAN mode and voice stream processing mode
 Security Mode of Voice VLAN
When voice VLAN is enabled for a port, you can configure its security mode to filter data stream. If
security mode is enabled, the port just forwards voice packets, and discards other packets whose
source MAC addresses do not match OUI addresses. If security mode is not enabled, the port
forwards all the packets.
Security Mode Packet Type Processing Mode
UNTAG packet
Packet with voice
VLAN TAG
When the source MAC address of the packet is the OUI
address that can be identified, the packet can be
transmitted in the voice VLAN. Otherwise, the packet will
be discarded.
Enable
Packet with other
VLAN TAG
The processing mode for the device to deal with the packet
is determined by whether the port permits the VLAN or
not, independent of voice VLAN security mode.
UNTAG packet
Packet with voice
VLAN TAG
Do not check the source MAC address of the packet and all
the packets can be transmitted in the voice VLAN.
Disable
Packet with other
VLAN TAG
The processing mode for the device to deal with the packet
is determined by whether the port permits the VLAN or not,
independent of voice VLAN security mode.
Table 9-3 Security mode and packets processing mode
126

TP-Link TL-SG5412F Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Fan	0
Wi-Fi	No
Diagnostics	VCT
Management platform	SNMP, RMON, WEB/CLI/Telnet
Authentication method	802.1X, Radius
Packet transfer speed	17.99Mpps
Connectivity technology	Wired
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
DHCP features	DHCP client
Security algorithms	SSH, SSL/TLS
Switch type	Managed
Switch layer	L2
Console port	RJ-45
Fiber optic connector	SFP
SFP/SFP+ slots quantity	12
Basic switching RJ-45 Ethernet ports quantity	4
Fiber ethernet cabling technology	100BASE-FX
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Stackable	-
Form factor	1U
Certification	CE, FCC
Product color	Black
Compatible operating systems	Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare\\r UNIX\\r Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	260 mm
Width	440 mm
Height	44 mm
