【F3.37】 The Current Level of Speed Tracing
a. When the drive current is greater than the current level of speed tracing (F3.37),
the output frequency is tracing downwardly to reach the current level of speed
tracing. The setting range is 0~200% of drive rated current.
b. The speed tracing function is mainly used for tracing the speed for the drive
restart after instantaneous power failure/flying start, the drive fault restart, or the
speed tracing command is given by the input terminal.
c. See the function description of F5.19~F5.22 multi-function input terminals for
speed tracing.
【F3.38】 Delay Time for Speed Tracing
Set the output delay time before the speed tracing.
The setting range is 0.1~60.0 sec.
【F3.39】 The V/F Pattern of Speed Tracing
Set the percentage of V/F output voltage for the speed tracing.
The setting range is 0~100%.
59
