F3 Control Parameters
Func. Name Descriptions
Range of
Setting
Unit
Factory
Setting
Note
F3.00
Holding
Frequency
The drive accelerate to the holding
frequency and running at constant
speed.
0.0~400.00 0.1Hz
0.5
*Note 9
F3.01
Holding Time
Interval
The drive runs at holding frequency
by constant speed and running the
time interval.
0.0~360.0 0.1sec
0.0
*Note 9
F3.03
Stall
Prevention
Level at the
Acceleration
If stall is occurred during
acceleration, the motor keeps
running at the constant speed(200%:
Off).
30%~200%
of drive
rated
current
1%
170
*Note 9
F3.04
Stall
Prevention
Level at the
Constant
Speed
If stall is occurred at constant speed
running, the motor speed is
decreased(200%: Off).
30%~200%
of drive
rated
current
1%
160
*Note 9
F3.05
Acceleration
Time for Stall
Prevention at
the Constant
Speed
Set the acceleration time for the stall
prevention of the constant speed.
0.1~3200.0 0.1sec
5.0
*Note 9
F3.06
Deceleration
Time for Stall
Prevention at
the Constant
Speed
Set the deceleration time at the stall
prevention of the constant speed.
0.1~3200.0 0.1sec 5.0
*Note 9
F3.07
Deceleration
Stall
Prevention
0: Deceleration stall prevention:
Disabled
1: Deceleration stall prevention:
Enabled
0, 1 ─
1
*Note 9
F3.09
Motor Slip
Compensation
ccording to the load condition, set
the motor slip compensation for
motor running at the constant speed
(0.0: Off).
-59.9~60.0 0.1Hz
0.0
*Note 9
F3.10
Frequency
Response
Time of
Motor Slip
Compensation
Set the frequency response time of
motor slip compensation. Unit: 5ms
1~255 1
40
*Note 9
F3.12
Automatic
Boost Voltage
Range
ccording to the load condition,
adjust the output voltage of the V/F
Pattern (0.0: Off).
0.0~25.5 0.1
1.0
*Note 9
The color as means functions can be set during the operation.
