TPG CA-202A - F4 Protection Parameters

F4 Protection Parameters
Func. Name Descriptions
Range of
Setting
Unit
Factory
Setting
Note
F4.07
Motor
Overload
Protection
(OL)
0: Motor overload protection:
Disabled
1: Motor overload protection:
Enabled(OL)
2: Motor overload protection of
independent cooling fans:
Enabled(OL)
0~2 ─ 1
*Note 9
F4.08
Motor Rated
Current
Current setting according to the moto
r
rated current.
10%~150%
of drive
rated current
0.1A
A
ccording
to the
rated
current of
motor
F4.09
Motor
No-Load
Current
Current setting according to the
motor’s no-load condition
0~ motor
rated current
0.1A
1/3 motor
rated
current
*Note 9
F4.10
Trip Time of
Motor
Overload
Set the tripped time of motor when
motor is overload(150% of Motor
rated current).
0.5~10.0 0.1min 5.0
*Note 9
F4.12
Protection
Level of
Drive
Overheat
Set the tripped level of drive when
drive is overheat.
85~115 1℃
90
*Note 6
*Note 9
F4.13
Drive
Overheat
Pre-alarm
Selection
0: Disable
1: Warning (OHt): Continuous
operation
(relay terminal outputs)
2: Warning (OHt): Reduce switching
frequency operation
(relay terminal outputs)
3: Warning (OHt): Stop operation
(relay terminal outputs)
0~3 ─ 2
*Note 9
The color as means functions can be set during the operation.
