Chapter 1 Cautions Before Installation
1-1 Product Verification
The product has passed the strictest quality test before shipped out from the
factory. However, the product might possibly sustain minor damages due to the
impact, shaking, vibration, and other factors during the transportation. Please
make sure to verify the following items after receiving this product. If the
product verification finds anything abnormal, please contact the agent
immediately for the further assistance.
1-1-1 Confirmation of Appearance
1.Check up the drive’s model number is identical with the shipping label on
the carton.
2.Check up the appearance of the drive for any paint chipped off,
smearing, deformation of shape, etc.
3.Check up the nameplate (as below figure) of the drive to verify the
product descriptions with the order specification.
XXXXXXXX
0201-1
3PH AC200-240V1.5A 0.1-400Hz
1PH AC200-240V 3A 50/60Hz
CA-202A
SERIAL NO.
PGM NO.
OUTPUT
INPUT
TYPE
Model Number
Input Power Specs
Output Current & Capacity
Sofware Number
Product Serial Number
ISO 9001 IP20
XXXXXXXXX
1-2 Standard Specifications
Model name CA CA-201A CA-202A
Maximum applicable motor (W) 125 200
Rated output capability (VA)
400
600
Rated output current (A) 0.9 1.5
Rated output voltage (V) Three-phase 200~240V
Range of output frequency (Hz) 0.1~400Hz
Power source (ψ, V, Hz) 1Ø, 200~240V , 50 / 60Hz
Input current (A) 1.7 3
Permissible AC power source
fluctuation
176V~264V 50/60Hz /±5%
Overload protection 150% of drive rated output current for 1 min.
Cooling method Nature cooling
Protective structure IP20
Weight / Mass(kg) 384g
