F2 Frequency Parameters
【F2.00】
Primary Speed (Preset Speed 1)
| |
【F2.07】 Preset Speed 8
【F2.16】 Jog Speed
a. Setting range: 0.00~400.00Hz
b. The settings are listed as below:
(I) Set the acceleration / deceleration time of multi-speed (F2.18~ F2.28)
(II) Set multi-function input terminals(F5.19~ F5.22)
c. Preset speed table
Jog
speed
command
Multi-speed
level 3
command
Multi-speed
level 2
command
Multi-speed
level 1
command
Name
ON
× × ×
Jog speed
OFF OFF OFF OFF
Primary Speed
(Preset Speed 1)
OFF OFF OFF ON Preset Speed 2
OFF OFF ON OFF Preset Speed 3
OFF OFF ON ON Preset Speed 4
OFF ON OFF OFF Preset Speed 5
OFF ON OFF ON Preset Speed 6
OFF ON ON OFF Preset Speed 7
OFF ON ON ON Preset Speed 8
※ “×”: Don’t care.
※Jog speed has the highest priority. That is, when the jog speed is on, all other
speed command are void.
※Jog speed and the multi-speed commands programmed by functions F5.19~
F5.21 to define multi-function input terminals (X1~X3) are given by input signals
ON and OFF to the multi-function input terminals.
※ON: “a” contact (normal open) is set and “b” contact (normal close) is open.
OFF: “a” contact (normal open) is open and “b” contact (normal close) is set.
