37
F6 Special Parameters
Func. Name Descriptions
Range o
Setting
Unit
Factory
Setting
Note
F6.55
Communication
ddress
The host uses the address to
send and receive messages
from the drive (0: Disable)
0~254 ─ 0
*Note 9
F6.56 Baud Rate
0: 4800bps
1: 9600bps
2: 19200bps
0~2 ─ 1
*Note 9
F6.57
Communication
Protocol
0: 8,N,2
1: 8,E,1
2: 8,O,1
0~2 ─ 1
*Note 9
F6.58
Communication
Overtime (Cot)
When the data transmission during
communication transmission is
interrupted, has no data transmitting,
or delays, drive displays “Cot”
message (0.0: Communication
overtime disable)
0.0~100.0 0.1sec 0.0
*Note 9
F6.59
Communication
Overtime
Disposal
0: Warning (Cot): Continue
operation.
1: Warning (Cot): Ramp to stop
2: Warning (Cot): Coast to stop
0~2 ─ 0
*Note 9
F6.60
Multi-Function
Input Selection
0: Multi-function inputs from
multi-function terminals
1: Multi-function inputs from
communication control
0, 1 ─ 0
*Note 9
(Note):
1. The default setting of 50Hz
2. The default setting of 60Hz (
Factory Setting)
3. Specifications of 100V series
4. Specifications of 200V series
5. Specifications of 400V series
6. The default value is “105” for 2003B1/2003B3~2005B3/4005B3~4007B3 models and the
default value is “90” for remained models.
7. + : Represents a contact (Normal open), ─ : Represents b contact (Normal close)
UP/DOWN control wiring must not exceed over 20m when multi-function terminals are used
for UP/DOWN control.
8. When the setting value of switching frequency(F1.21) exceeds “4”, the drive must be de-rating
for usage or selecting the higher capacity of drive.
9. Setting F0.18=1.
The color as means functions can be set during the operation.
