TPG CA-202A - Page 26

Func. Name Descriptions
Range of
Setting
Unit
Factory
Setting
Note
50.0
*Note 1
F2.32
Maximum
Output
Frequency
Maximum output frequency of drive 0.1~400.00 0.1Hz
60.0
*Note 2
F2.33
Starting
Frequency
Starting frequency of drive’s output
frequency.
0.1~10.0 0.1Hz 0.5
*Note
9
0.1~50.0
*Note 3,4
8.0
*Note 3,4
F2.34
Starting
Voltage
The voltage corresponds to the output
starting frequency.
0.1~100.0
*Note 5
0.1Vac
12.0
*Note 5
50.0
*Note 1
F2.35
Base
Frequency
The frequency corresponds to the base
voltage in V/F pattern.
0.1~400.00 0.1Hz
60.0
*Note 2
0.1~255.0
*Note 3,4
220.0
*Note 3,4
F2.36
Base Voltage
The voltage corresponds to the base
frequency in V/F pattern.
0.1~510.0
*Note 5
0.1Vac
380.0
*Note 5
F2.37
V/F
Frequency 1
Frequency at the first point of V/F
pattern
0.0~399.9 0.1Hz 0.0
*Note
9
0.0~255.0
*Note 3,4
F2.38
V/F
Voltage 1
Voltage at the first point of V/F pattern
0.0~510.0
*Note 5
0.1Vac 0.0
*Note
9
F2.39
V/F
Frequency 2
Frequency at the second point of V/F
pattern.
0.0~399.9 0.1Hz 0.0
*Note
9
0.0~255.0
*Note 3,4
F2.40
V/F
Voltage 2
Voltage at the second point of V/F
pattern.
0.0~510.0
*Note 5
0.1Vac 0.0
*Note
9
F2.42
Jump
Frequency 1
A
void mechanical resonance point 1. 0.0~400.00 0.1Hz 0.0
*Note
9
F2.43
Jump
Frequency 2
A
void mechanical resonance point 2. 0.0~400.00 0.1Hz 0.0
*Note
9
F2.44
Jump
Frequency 3
A
void mechanical resonance point 3. 0.0~400.00 0.1Hz 0.0
*Note
9
F2.45
Jump
Frequency
Range
Set the range of the jump frequency 1,
2, 3.
0.0~25.5 0.1Hz 0.0
*Note
9
F2.47
Frequency
Upper Limit
The upper limit of output frequency
(1.00=maximum output frequency)
0.00~1.00 0.01 1.00
F2.48
Frequency
Lower Limit
The lower limit of output frequency
(1.00=maximum output frequency)
0.00~1.00 0.01 0.00
The color as means functions can be set during the operation.
26
