TPG CA-202A - Page 25

Func. Name Descriptions
Range
of
Setting
Unit
Factory
Setting
Note
F2.19
Primary
Deceleration
Time
The deceleration time of primary speed,
preset speed 5~16, and jog speed.
0.0~
3200.0
0.1
sec
5.0
F2.20
Acceleration
Time of
Preset
Speed 2
A
cceleration time of preset speed 2
0.0~
3200.0
0.1
sec
5.0
*Note
9
F2.21
Deceleration
Time of
Preset
Speed 2
Deceleration time of preset speed 2
0.0~
3200.0
0.1
sec
5.0
*Note
9
F2.22
Reserved Reserved
─ ─ ─
*Note
9
F2.23
Reserved Reserved
─ ─ ─
*Note
9
F2.24
Reserved Reserved
─ ─ ─
*Note
9
F2.25
Reserved Reserved
─ ─ ─
*Note
9
F2.26
Secondary
Acceleration
Time
Multi-function input terminals select the
secondary acceleration time.
0.0~
3200.0
0.1
sec
5.0
*Note
9
F2.27
Secondary
Deceleration
Time
Multi-function input terminals select the
secondary deceleration time.
0.0~
3200.0
0.1
sec
5.0
*Note
9
F2.28
Set S-curve
for
Accel/Decel
Time
Set S-curve to slow the acceleration and
deceleration at start and stop.
0.0~5.0
0.1
sec
0.0
*Note
9
F2.30
Reserved Reserved
─ ─ ─
*Note
9
F2.31
V/F Pattern
Selection
0: Linear
1: Energy saving mode (auto-adjust V/F
according to the loads)
2: Square curve
3: 1.7
th
power curve
4: 1.5
th
power curve
0~4 ─ 0
*Note
9
The color as means functions can be set during the operation.
25
