Start method
Command the drive via 3 programmable multi-function input
terminals(X1~X3): Forward command / Reverse command,
3-wire start/stop control, 8 sets preset speed control.
4 programmable input terminals: X1~X3
Response time (1~255, unit: 1ms)
Multi-function
inputs
Refer to the chapter of function setting description for
F5.19~F5.21.
1 set of analog inputs: AI(DC 0~10V / 2~10V or DC 0~20mA /
4~20mA)
Analog filter (0~255, unit: 5ms), the dead band of
Analog frequency, gain and bias are adjustable.
Input
Analog inputs
Refer to the chapter of function setting description for F5.01,
F5.02.
1-set programmable output terminal: Ta / Tc Multi-function
outputs
Refer to chapter of function setting description for F5.26.
1 set of analog output: FM(DC 0~10V / 2~10V or DC 0~20mA
/ 4~20mA)
The gain and bias are adjustable.
Operation Characteristics
Output
Analog
outputs
Refer to the chapter of function setting description for
F5.12~F5.15.
Atmosphere
Non-corrosive or non-conductive, or non-explosive gas or
liquid, and non-dusty
Surrounding
temperature
-10°C (14°F) ~ +50°C (122°F) (Non-freezing and
non-condensing)
Storage
temperature
-20°C (-4°F) ~ +60°C (149°F)
Relative humidity 90% RH or less (No-condensing atmosphere)
Vibration Less than 5.9m/sec² (0.6G)
Altitude Less than 1000m (3280 ft.)
