4.2.6 CAPTURE Button
Pressing the CAPTURE button allows you to quickly select the capture source for a Remix
Deck.
CAPTURE Button
The capture Source can be selected by holding the CAPTURE button and turning the BROWSE
encoder. Pressing a pad will then sample content from the Deck set as Capture source to the
corresponding Remix Cell.
The capture size is determined by the source Deck's loop size setting.
4.2.7 Display Area and Controls
On the D2's graphic color display, some functionality is dynamically shown or hidden by means
of the Display buttons adjacent to the display. The following image and table give a detailed
overview of the Display area and controls and provide links referring to sections with further
information.
