Repair
Replacing the drum
94
Operating instructions: Belt conveyor TS 1208
Version 1.6ENG, 10/04/2018
3. Remove the bottom conveyor track cover (3).
The covers have been removed.
Removing the drive
drum
Increased risk of accident!
The drive drum may tip over and crush body parts.
Secure the drive drum to prevent it falling.
Use hoists to lift drive drum on and off.
Carry out the following work steps:
1. Remove the joining elements (5) of the flange bearing (4).
