Camera compensation system for print&cut applications
Exhaust mounted to working head
Digitally controlled sectioning of table exhaust; 4 exhaust sections
Ultrasonic-based autofocus system
CAD / CAM software for perfect cutting results; nesting-function, lead-
in/lead-out, tool paths, etc. included
Comprehensive package of technical services
Dimensions (W x D x H) & Weight
3.076 x 3.914 x 1.230 mm (121 x 154 x 49 in)
720 x 835 x 930 mm (117 x 33 x 37 in) (400 watts model)
130 kg (287 lbs) (400 watts model)
800 x 600 x 1.126 mm (32 x 24 x 45 in)
2.082 x 714 x 2.852 mm (82 x 29 x 113 in)
Fully enclosed beam path CDRH laser safety class 4 laser; can be op-
erated like laser class 2 in standard operation mode
Fully enclosed beam path as well as active laser deflector shield at
working head
Light barriers and safety bumpers for beam path and gantry
Encoded duplicate interlock safety system
Mandatory ambient temperature +15° to +25° C or 59° to 77° F
Humidity 40% to max. 70%, not condensing
Dust free environment (2nd degree according to IEC 60947-1)
Min. 2.500 m³/h at 800 Pa (Min. 1.200 cfm at 8.900 in H
2
O)
(Table exhaust)
Min. 100 m³/h at 4.450 Pa (Min. 60 cfm at 17.865 in H
2
O)
(Travelling exhaust)
Minimum requirement for acrylic cutting; Depending on application
Voltage & power consumption
3x400V (3xL+N+PE) 50/60Hz, max. 1,6 kW (60 watts)
3x400V (3xL+N+PE) 50/60Hz, max. 3,1 kW (100 watts)
3x400V (3xL+N+PE) 50/60Hz, max. 4,5 kW (200 watts)
3x400V (3xL+N+PE) 50/60Hz, max. 8,4 kW (400 watts)
