Safety
Test procedure
■
Move portal in rapid traverse in y-direction.
– To do this, press the shortcut shift-button + laser head control button Y+ (see chapter Shortcuts).
Correct functioning: Automatic motor braking of the portal is initiated.
Distance between holder for head exhaust tubing and test block must be at least 20 mm!
Figure 3: Distance after successful check.
34 ENGLISH (Translation)
