Trox Technik FKR-EU - Page 156

Item
no.
Description
6 Filling and coating material
6.19 Mineral wool > 1000°C, > 80 kg/m³, panel
material around the perimeter
, leave out the
actuator and release mechanism; inspection
accesses must remain accessible
6.20 Sleeve (can be ordered separately)
6.21 Kerafix 2000 sealing tape
6.22 Screed
6.23 Footfall sound insulation
6.24 Elastomer foam (synthetic rubber) of fire
rating class B-S3, D0
6.25 Mineral wool or glass wool fill
6.26 Plaster
6.27 Holding plate on both sides,
90 × 140 × 1.5 mm
6.28 Ceiling fill
6.29 Mineral wool Paroc HVAC Fire Mat
6.30 Double layer mineral wool Paroc HVAC Fire
Mat 80BLC (80 kg/m³)
6.31 Fire-rated plasterboard strip, d = 12.5 mm
6.32 Fire-rated plasterboard strip, d = 20 mm
6.33 Fire-rated plasterboard strip, d = 15 mm
Item
no.
Description
7 Supporting construction
7.1 UW section
7.1a UW section, cut and bent
7.2 CW section (metal support structure)
7.3 UA section
7.4 U50 channel
7.5 Steel support structure
7.6 Perimeter metal section
7.7 Timber stud, at least 60 × 80 mm
7.8 Steel girder
7.9 Timber structure
7.10 Trim panels (optional)
7.11 Trim panels, double layer, staggered joints
7.12 Trim panels, wood sheet, at least 600 kg/³
7.13 Cladding / wall cladding
7.13a Cladding, fire-resistant
Item
no.
Description
7 Supporting construction
7.13b Cladding, wood sheet, at least 600 kg/³
7.13.1 Cladding, single-layer, adjusted
7.14 Reinforcing strip
7.15 Wooden floorboard / floor tile / wood sheet
min. 600 kg/m³
7.16 Wooden beam / glued laminated timber
7.17 Trimmers in general
7.18 Formwork
7.19 Fire-resistant cladding
7.20 U-channel
7.21 Ceiling joint strips
7.22 Ceiling joint section
7.23 Sheet steel insert depending on wall manu-
facturer
7.24 Ceiling design
7.25 Reinforced concrete support
7.26 Hollow stone
7.27 Profile sheet metal
Item
no.
Description
8 Material for extended applications
8.1 PROMATECT®-H strips, d = 10 mm
8.2 PROMATECT®-H strips, d = 20 mm
8.3 PROMATECT®-LS board d = 35 mm
8.4 Hilti mounting rail MQ 41 × 3 or equivalent
8.5 Hilti drilled plate MQZ L13 or equivalent
8.6 Hilti fixing band LB26 or equivalent
8.7 Mounting rail, Würth Varifix 36 ×
36 × 2.5 or
Müpro MPC 38/40 or equivalent
8.8 Fixing bracket, Varifix or Müpro MPC or
equivalent
8.9 Bracket, Varifix ANSHWNKL-
PRFL36-90GRAD or Müpro mounting
bracket 90°, galvanised, or equivalent
8.10 Large gears
8.11 Actuator
8.12 Actuator mounting plate
8.13 Small gears
8.14 Connecting cable
Nomenclature
Fire damper FKR-EU156
