Item
no.
Description
8 Material for extended applications
8.15 Adjustment screws
8.16 Actuator mounting plate
8.17 Cover
8.18 Junction box
8.19 Outlay from 8.3
8.20 Promaseal®-Mastic intumescent sealant
8.21 Fire-resistant sealant CFS-S ACR CW
8.22 Calcium silicate board, or alternatively min-
eral wool ≥
1000°C, ≥ 140 kg/m³
8.23 Foam rubber seal
8.24 Retaining plate on both sides, sheet steel
≥ 1 mm
thick
8.25 Bracket, e.g. Hilti MM-B-30 or equivalent
8.26 Blanking plate, t = 1 mm
8.27 Seal
8.28 PROMATECT®-H strips, d = 15 mm
8.29 PROMATECT®-H strips, d = 25 mm
8.30 PROMATECT®-AD, d = 40 mm
8.31 PROMATECT®-L500, d = 50 mm
8.32 Outlay from 8.30
8.33 Outlay from 8.31
8.34 Sealing tape type Flexan
8.35 Intumescent material
8.36 Promaxon® construction plate type A,
d = 20 mm
8.37 Steel bracket
8.38 OWA adhesive
8.39 Spigots, comprising spiral duct and
2 Ï raised edge
Item
no.
Description
9 Accessories
9.1 Flexible connector
9.2 Extension piece or duct
9.3 Prop
9.4 Sheet steel duct with fire-resistant cladding
and suspension system according to
Promat® manual, construction 478, latest
edition
Item
no.
Description
9 Accessories
9.5 Suspension
9.6 Repair damper blade
9.7 Damper blade
9.8 Rivet axis
9.9 Plate
9.10 Cover grilles
9.11 Circular spigot
9.12 Clamping ring
9.13 Reinforcement bracket
9.14 Profile connecting frame
9.15 T-piece
Item
no.
Description
10 Release mechanisms
10.1 Spring return actuator
10.2 Spring return actuator Belimo BLF
10.3 Spring return actuator Belimo BF
10.4 Spring return actuator Belimo BFN
10.5 Spring return actuator Belimo BFL
10.6 Spring return actuator Schischek ExMax
(yellow)
10.7 Spring return actuator Schischek RedMax
(magenta)
10.8 Spring return actuator Siemens GGA
10.9 Spring return actuator Siemens GRA
10.10 Spring return actuator Siemens GNA
10.11 Spring return actuator Joventa SFR
10.12 Duct smoke detector RM-O-3-D (fixed with
adapter metal sheet)
10.13 Thermoelectric release mechanism with tem-
perature sensor
10.14 Thermal release mechanism with fusible link,
72 °C / 95 °C
10.15 Fusible link holder
10.16 Fusible link holder rocker
10.17 Screw
10.18 Fusible link
10.19 Cover
